The two-way ball valve is used to detect the safety valve type VS224 and to remove it for periodic recalibration, without having to fully discharge all the nitrogen of accumulator/accumulator station. The ball of the valve is located between two pre- compressed seals provided with a floating system, so it is guaranteed a perfect seal at both low and high pressure.
Shut off 2_way valves gas side
MAX OPERATING PRESSURE: 320 bar
MINIMUM DIAMETER: 19 mm
WORKING TEMPERATURE: -20 ÷ 100
FLUID VISCOSITY RANGE: 10 ÷ 400 cSt
BODY MATERIAL: phosphated carbon steel
SEALS: polyacetal resin and NBR
These Shut off 2_way valves allow safe removal and recalibration of safety valves without fully discharging nitrogen, while their floating seal system ensures a reliable leak-free performance at both low and high pressures.
