The electrical limit switch device consists of a non-magnetic casing, a switch rod with a set of permanent magnets, 1 break contact limit switch (NCC) and/or 1 close contact limit switch (NOC). The limit switch unit, and its seal is installed on the end of the accumulator.
Piston Positioning Monitoring
Electrical limit switching device "ES"
• Stroke 75 mm with on contact breaker and one contact opener overall length L = 250 mm
• Stroke 50 mm with one break contact (NCC) or one open contact (NOC) including, overall length L = 168 mm
• Spring reset for any required installation position
• Special design for oil side with additional bypass tube for pressure balance, overall length on request
The stroke area to be controlled can be up to 1,500 mm, independent of the total piston stroke. Since monitoring 50% of the stroke is usually sufficient, the entire piston stroke can be managed within a compact space.
